Strong engineering outcomes rely on clear, accurate and buildable documentation.
At Ingenia, our design and drafting services transform concepts into coordinated engineering deliverables that support fabrication, construction and project delivery. Our multidisciplinary team works across mechanical, structural and civil disciplines, combining practical engineering knowledge with detailed documentation.
From concept development through to detailed design packages, we focus on producing documentation that supports constructability, maintainability and project performance.
Engineering-Led Drafting
Our drafting capability is integrated with our engineering services, meaning designs are developed with practical application in mind.
Our team supports:
Mechanical Design and Drafting
Documentation for:
- Machinery and equipment
- Material handling systems
- Process equipment
- Pressure vessels
- Plant upgrades
Structural Design and Drafting
Documentation and modelling for:
- Structural steel
- Platforms and access systems
- Industrial infrastructure
- Plant modifications
Civil Design and Drafting
Support for:
- Site layouts
- Infrastructure works
- Drainage and civil components
- Multidisciplinary projects
How We Work?
Our design process is developed around practical engineering outcomes and coordinated project delivery:
- End-to-End Integration: Design and drafting activities are integrated with broader engineering, project management and risk activities.
- Constructability Focus: We consider how designs will be fabricated, installed, operated and maintained throughout the project lifecycle. Coordination Across Disciplines Our multidisciplinary approach improves communication and helps reduce design conflicts across projects.
Specialised Industry Applications
Engineering documentation requirements vary significantly between industries. Our design and drafting approach is tailored to suit operational requirements, project environments and delivery needs.
- Industrial and Manufacturing: Documentation and modelling support for machinery design, production line upgrades, plant modifications and process improvements.
- Mining and Resources: Structural steel, materials handling systems, plant infrastructure and multidisciplinary project coordination for heavy industrial environments.
- Infrastructure and Major Projects: Civil, structural and multidisciplinary documentation packages supporting larger project environments and complex stakeholder requirements.
- Materials Handling: Engineering documentation and modelling for conveying systems, transfer stations, storage infrastructure and associated plant equipment.
Technology and Project Delivery Tools
We use industry-standard platforms and workflows to improve accuracy and project coordination.
- BIM and Coordination Workflows: Using Revit, Inventor and BIM methodologies, we develop coordinated project information and identify potential issues early.
- Scanning to CAD: Using terrestrial laser scanning and site capture technologies, existing facilities can be converted into accurate digital information where drawings are incomplete or unavailable.
- Visualisation and Design Review: Digital review tools and visualisation workflows support stakeholder engagement and design coordination.
The Ingenia Process
We value the finished product of your project, and we ensure that every step of our process guarantees a successful finish. Here’s the Ingenia process:
- Site Capture and Discovery: We establish project requirements and collect site information through drawings, site investigations and terrestrial scanning technologies where required.
- Concept Development: Concept designs and layouts are developed to communicate project intent and assess options.
- Detailed Design and Documentation: Detailed engineering drawings and coordinated documentation packages are produced to support project delivery.
- Review and Refinement: Documentation is reviewed collaboratively to improve coordination and identify opportunities for improvement.
- Project Support: Our team can continue supporting projects through implementation and ongoing project activities.
FAQ’s (Frequently Asked Questions)
Is your drafting team made up of qualified engineers?
Our drafting team works closely with mechanical, structural and civil engineers to develop coordinated and practical engineering documentation.
What is delivered at the end of a project?
Deliverables vary depending on project scope and may include 3D models, detailed drawings, coordinated layouts, PDFs and supporting project documentation.
Draft With Ingenia Today
Not sure what your plant upgrade will look like? Reach out to our team at Ingenia for draft designs that help you visualise the finished product.
